SCHNEIDER EASYPACT CVS400F MCCB BREAKER, 36 KA AT 415 VAC, 3P 3D, MA 320A

Range of product : Easypact CVS400...630 Product or component type : Circuit breaker Device short name : CVS400F Device application : Motor Poles description : 3P Protected poles description : 3d Earth leakage protection (Vigi add on) : Without [In] rated current : 400 A at 40 °C Breaking capacity code : F Network type : AC [Icu] Breaking capacity : 40 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-236 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-230 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 Utilisation category : Category A Trip unit name : MA Trip unit technology : Magnetic Trip unit rating : 320 A at 40 °C Protection type : Short-circuit protection (magnetic)

Specifications:

• Breaking Capacity: 30 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
• Breaking Capacity Code: F
• Contacts Type And Composition: 400 A at 40 °C
• Control Type: toggle
• Product Or Component Type: circuit breaker
• Range Of Product: EasyPact CVS400...630
• Trip Unit Name: MA
• [Ie] Rated Operational Current: toggle
• Device Short Name: CVS400F
• Mounting Support: backplate
• Network Type: AC
• Protected Poles Description: 3d
• Range: EasyPact
• Range Name: EasyPact CVS
• Trip Unit Technology: magnetic
• Utilisation Category: category A
• Current Transformer Type: F
• Interlocked Device: 30 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
• Product Name: EasyPact CVS
• [Ics] Rated Service Breaking Capacity: 23 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
• [In] Rated Current: 400 A at 40 °C
• Compatibility Code: CVS400
• Connection Pitch: 45 mm
• Connections - Terminals: screw connection
• Contact Position Indicator: yes
• Depth: 110 mm
• Device Application: motor
• Downside Connection: front
• Earth-leakage Protection: without
• Electrical Durability: 6000 cycles 415 V In conforming to IEC 60947-2
• Height: 255 mm
• Instantaneous Pick-up Adjustment Range: 6...13 x In
• Instantaneous Pick-up Adjustment Type Ii: adjustable
• Mechanical Durability: 15000 cycles
• Mounting Mode: fixed
• Net Weight: 4.7 kg
• Network Frequency: 50/60 Hz
• Protection Type: short-circuit protection (magnetic)
• Short-time Pick-up Adjustment Type Isd: adjustable
• Trip Unit Rating: 320-320 A at 40 °C
