MAKITA DJR189 CORDLESS RECIPRO SAW SPARE PARTS

Spare Parts of Makita DJR189 Recipro Saw Ref. No. Part Name & Number Price 001 MAKITA TAPPING SCREW BIND PT 3X16 FOR 6226DWE P/N:266130-9 Part No.: 266130-9 $0.11 Add To Cart 003 MAKITA HOUSING SET FOR DJR189 P/N:183W50-9 Part No.: 183W50-9 $21.36 Add To Cart 004 MAKITA LED CIRCUIT FOR DJR189 P/N:620K03-0 Part No.: 620K03-0 $5.23 Add To Cart 005 MAKITA TAPPING SCREW PT 2X6 FOR DDF083 P/N:266490-9 Part No.: 266490-9 $0.33 Add To Cart 006 MAKITA FLAT HEAD SCREW M3X6 P/N:652069-6 Part No.: 652069-6 $0.22 Add To Cart 007 MAKITA CUSHION P/N:424517-3 Part No.: 424517-3 $0.44 Add To Cart 008 MAKITA TERMINAL FOR DTP/DDF/DHP484 P/N:643874-2 Part No.: 643874-2 $3.92 Add To Cart 010 MAKITA CONTROLLER FOR DJR189 P/N:620K04-8 Part No.: 620K04-8 $111.51 Add To Cart 011 MAKITA STATOR FOR DJR189 P/N:629B65-1 Part No.: 629B65-1 $10.25 Add To Cart 012 MAKITA SWITCH C3JW-4B FOR DDF/DHP484 P/N:650710-5 Part No.: 650710-5 $18.53 Add To Cart 013 MAKITA LOCK OFF BUTTON FOR DJR189 P/N:413L03-1 Part No.: 413L03-1 $0.55 Add To Cart 015 MAKITA ROTOR ASS'Y FOR DJR189 P/N:519770-5 Part No.: 519770-5 $27.90 Add To Cart 018 MAKITA RETAINING RING S-10 FOR HR3000C HR2810 P/N:961006-2 Part No.: 961006-2 $0.33 Add To Cart 019 MAKITA HEX. SOCKET HEAD BOLT M4X12 FOR 4340CT P/N:265353-6 Part No.: 265353-6 $0.44 Add To Cart 020 MAKITA HEX.S.FLANGE HEAD BOLT M5X12 P/N:265C93-4 Part No.: 265C93-4 $0.65 Add To Cart 021 MAKITA HEX. SOCKET HEAD BOLT M4X12 FOR 4340CT P/N:265353-6 Part No.: 265353-6 $0.44 Add To Cart 022 MAKITA BEARING RETAINER 33 FOR DJR189 P/N:285055-8 Part No.: 285055-8 $0.65 Add To Cart 024 MAKITA GEAR HOUSING ASS'Y FOR DJR189 P/N:136824-9 Part No.: 136824-9 $14.72 Add To Cart 025 MAKITA GEAR COMPLETE FOR DJR189 P/N:141L92-3 Part No.: 141L92-3 $22.89 Add To Cart 026 MAKITA SHOE FOR DJR189 P/N:162B95-4 Part No.: 162B95-4 $7.19 Add To Cart 027 MAKITA HEX.S.BUTTON HEAD BOLT M4X12 P/N:265C84-5 Part No.: 265C84-5 $0.55 Add To Cart 028 MAKITA SEAL RING FOR DJR189 P/N:422950-3 Part No.: 422950-3 $0.76 Add To Cart 030 MAKITA R. RING FOR DC/AC-JR P/N:257430-8 Part No.: 257430-8 $0.55 Add To Cart 032 MAKITA SHOULDER PIN 5 FOR JR3070CT P/N:256569-4 Part No.: 256569-4 $0.87 Add To Cart 033 MAKITA SPRING 6 FOR DC/AC-JR P/N:234381-2 Part No.: 234381-2 $0.22 Add To Cart 035 MAKITA PIN 3 FOR JR002G P/N:256A11-1 Part No.: 256A11-1 $0.22 Add To Cart 036 MAKITA CONNECTING SLEEVE FOR DC-JR P/N:458968-8 Part No.: 458968-8 $0.55 Add To Cart 037 MAKITA PUSH PIN FOR DC/AC-JR P/N:310912-2 Part No.: 310912-2 $1.96 Add To Cart 038 MAKITA COMPRESSION SPRING 2 FOR DJR188 P/N:232472-3 Part No.: 232472-3 $0.76 Add To Cart 039 MAKITA TOPSION SPRING 17 FOR DC-JR P/N:233594-2 Part No.: 233594-2 $0.76 Add To Cart 044 MAKITA SLIDER GUIDE FOR DJR189 P/N:313450-3 Part No.: 313450-3 $0.76 Add To Cart 045 MAKITA HOUSING SET FOR DJR189 P/N:183W50-9 Part No.: 183W50-9 $21.36 Add To Cart 046 MAKITA PLATE A FOR DJR189 P/N:347A47-2 Part No.: 347A47-2 $0.33 Add To Cart 047 MAKITA HEX. SOCKET HEAD BOLT M4X12 FOR 4340CT P/N:265353-6 Part No.: 265353-6 $0.44 Add To Cart 048 MAKITA COLLARED SLEEVE 8 FOR DJR189 P/N:327A55-9 Part No.: 327A55-9 $1.31 Add To Cart 049 MAKITA COUNTER WEIGHT FOR DJR189 P/N:313446-4 Part No.: 313446-4 $5.34 Add To Cart 050 MAKITA PLATE R FOR DJR189 P/N:347A49-8 Part No.: 347A49-8 $0.44 Add To Cart 051 MAKITA PLATE F FOR DJR189 P/N:347A48-0 Part No.: 347A48-0 $0.33 Add To Cart 052 MAKITA GASKET FOR DJR189 P/N:422952-9 Part No.: 422952-9 $2.07 Add To Cart 053 MAKITA GEAR HOUSING COVER FOR DJR189 P/N:312D37-2 Part No.: 312D37-2 $5.56 Add To Cart 054 MAKITA PAN HEAD SCREW M4X20 P/N:911138-5 Part No.: 911138-5 $0.33 Add To Cart 055 MAKITA SLIDER ASS'Y FOR DJR189 P/N:136867-1 Part No.: 136867-1 $40.98 Add To Cart

Brand: Makita

Specifications:

• Ref. No.: Part Name & Number
• 001: MAKITA TAPPING SCREW BIND PT 3X16 FOR 6226DWE P/N:266130-9 Part No.: 266130-9
• 003: MAKITA HOUSING SET FOR DJR189 P/N:183W50-9 Part No.: 183W50-9
• 004: MAKITA LED CIRCUIT FOR DJR189 P/N:620K03-0 Part No.: 620K03-0
• 005: MAKITA TAPPING SCREW PT 2X6 FOR DDF083 P/N:266490-9 Part No.: 266490-9
• 006: MAKITA FLAT HEAD SCREW M3X6 P/N:652069-6 Part No.: 652069-6
• 007: MAKITA CUSHION P/N:424517-3 Part No.: 424517-3
• 008: MAKITA TERMINAL FOR DTP/DDF/DHP484 P/N:643874-2 Part No.: 643874-2
• 010: MAKITA CONTROLLER FOR DJR189 P/N:620K04-8 Part No.: 620K04-8
• 011: MAKITA STATOR FOR DJR189 P/N:629B65-1 Part No.: 629B65-1
• 012: MAKITA SWITCH C3JW-4B FOR DDF/DHP484 P/N:650710-5 Part No.: 650710-5
• 013: MAKITA LOCK OFF BUTTON FOR DJR189 P/N:413L03-1 Part No.: 413L03-1
• 015: MAKITA ROTOR ASS'Y FOR DJR189 P/N:519770-5 Part No.: 519770-5
• 018: MAKITA RETAINING RING S-10 FOR HR3000C HR2810 P/N:961006-2 Part No.: 961006-2
• 019: MAKITA HEX. SOCKET HEAD BOLT M4X12 FOR 4340CT P/N:265353-6 Part No.: 265353-6
• 020: MAKITA HEX.S.FLANGE HEAD BOLT M5X12 P/N:265C93-4 Part No.: 265C93-4
• 021: MAKITA HEX. SOCKET HEAD BOLT M4X12 FOR 4340CT P/N:265353-6 Part No.: 265353-6
• 022: MAKITA BEARING RETAINER 33 FOR DJR189 P/N:285055-8 Part No.: 285055-8
• 024: MAKITA GEAR HOUSING ASS'Y FOR DJR189 P/N:136824-9 Part No.: 136824-9
• 025: MAKITA GEAR COMPLETE FOR DJR189 P/N:141L92-3 Part No.: 141L92-3
• 026: MAKITA SHOE FOR DJR189 P/N:162B95-4 Part No.: 162B95-4
• 027: MAKITA HEX.S.BUTTON HEAD BOLT M4X12 P/N:265C84-5 Part No.: 265C84-5
• 028: MAKITA SEAL RING FOR DJR189 P/N:422950-3 Part No.: 422950-3
• 030: MAKITA R. RING FOR DC/AC-JR P/N:257430-8 Part No.: 257430-8
• 032: MAKITA SHOULDER PIN 5 FOR JR3070CT P/N:256569-4 Part No.: 256569-4
• 033: MAKITA SPRING 6 FOR DC/AC-JR P/N:234381-2 Part No.: 234381-2
• 035: MAKITA PIN 3 FOR JR002G P/N:256A11-1 Part No.: 256A11-1
• 036: MAKITA CONNECTING SLEEVE FOR DC-JR P/N:458968-8 Part No.: 458968-8
• 037: MAKITA PUSH PIN FOR DC/AC-JR P/N:310912-2 Part No.: 310912-2
• 038: MAKITA COMPRESSION SPRING 2 FOR DJR188 P/N:232472-3 Part No.: 232472-3
• 039: MAKITA TOPSION SPRING 17 FOR DC-JR P/N:233594-2 Part No.: 233594-2
• 044: MAKITA SLIDER GUIDE FOR DJR189 P/N:313450-3 Part No.: 313450-3
• 045: MAKITA HOUSING SET FOR DJR189 P/N:183W50-9 Part No.: 183W50-9
• 046: MAKITA PLATE A FOR DJR189 P/N:347A47-2 Part No.: 347A47-2
• 047: MAKITA HEX. SOCKET HEAD BOLT M4X12 FOR 4340CT P/N:265353-6 Part No.: 265353-6
• 048: MAKITA COLLARED SLEEVE 8 FOR DJR189 P/N:327A55-9 Part No.: 327A55-9
• 049: MAKITA COUNTER WEIGHT FOR DJR189 P/N:313446-4 Part No.: 313446-4
• 050: MAKITA PLATE R FOR DJR189 P/N:347A49-8 Part No.: 347A49-8
• 051: MAKITA PLATE F FOR DJR189 P/N:347A48-0 Part No.: 347A48-0
• 052: MAKITA GASKET FOR DJR189 P/N:422952-9 Part No.: 422952-9
