MAKITA DJR188 CORDLESS RECIPRO SAW SPARE PARTS

Spare Parts of Makita DJR188 Recipro Saw Ref. No. Part Name & Number Price 001 MAKITA PROTECTOR FOR DJR188 P/N:422223-4 Part No.: 422223-4 $0.65 Add To Cart 002 MAKITA DRIVING SLEEVE FOR DC/AC-JR P/N:310848-5 Part No.: 310848-5 $6.21 Add To Cart 004 MAKITA PIN 3 FOR DC/AC-JR P/N:268094-3 Part No.: 268094-3 $0.33 Add To Cart 006 MAKITA SPRING 6 FOR DC/AC-JR P/N:234381-2 Part No.: 234381-2 $0.22 Add To Cart 007 MAKITA SHOULDER PIN 5 FOR JR3070CT P/N:256569-4 Part No.: 256569-4 $0.87 Add To Cart 008 MAKITA CONNECTING SLEEVE FOR JR188D P/N:458113-5 Part No.: 458113-5 $0.44 Add To Cart 009 MAKITA PUSH PIN FOR JR100D P/N:310859-0 Part No.: 310859-0 $1.96 Add To Cart 010 MAKITA COMPRESSION SPRING FOR 6702D Part No.: 233025-1 $0.33 Add To Cart 011 MAKITA TOPSION SPRING 17 FOR DC-JR P/N:233594-2 Part No.: 233594-2 $0.76 Add To Cart 014 MAKITA SLIDER FOR JR188D P/N:161796-9 Part No.: 161796-9 $9.27 Add To Cart 015 MAKITA ROLLER FOR JR187D P/N:310663-7 Part No.: 310663-7 $0.44 Add To Cart 016 MAKITA PIN 6 FOR JR3061T P/N:268341-2 Part No.: 268341-2 $0.22 Add To Cart 019 MAKITA PAN HEAD SCREW M4X16 P/N:911128-8 Part No.: 911128-8 $0.11 Add To Cart 020 MAKITA GEAR HOUSING R FOR DJR188D P/N:144809-1 Part No.: 144809-1 $11.55 Add To Cart 021 MAKITA ROD GUIDE R FOR JR188D P/N:347303-4 Part No.: 347303-4 $0.87 Add To Cart 022 MAKITA HEX. SOCKET HEAD BOLT M4X12 FOR 4340CT P/N:265353-6 Part No.: 265353-6 $0.44 Add To Cart 023 MAKITA SHOULDER PIN 6-8 FOR DJR18* P/N:256567-8 Part No.: 256567-8 $0.76 Add To Cart 025 MAKITA GEAR COMPLETE FOR JR188D P/N:144806-7 Part No.: 144806-7 $21.04 Add To Cart 026 MAKITA HEX. SOCKET HEAD BOLT M4X12 FOR 4340CT P/N:265353-6 Part No.: 265353-6 $0.44 Add To Cart 027 MAKITA ROD GUIDE L FOR JR188D P/N:347302-6 Part No.: 347302-6 $0.87 Add To Cart 028 MAKITA SEAL RING FOR JR188D P/N:422224-2 Part No.: 422224-2 $0.87 Add To Cart 029 MAKITA FLAT WASHER 45 FOR HR4001C Part No.: 267336-2 $1.31 Add To Cart 030 MAKITA GEAR HOUSING L FOR DJR188D P/N:144808-3 Part No.: 144808-3 $22.56 Add To Cart 032 MAKITA FLAT WASHER 4 FOR JR188D P/N:253400-5 Part No.: 253400-5 $0.55 Add To Cart 033 MAKITA HEX. SOCKET HEAD BOLT M4X12 FOR 4340CT P/N:265353-6 Part No.: 265353-6 $0.44 Add To Cart 034 MAKITA BEARING RETAINER 51 FOR JR188D P/N:285031-2 Part No.: 285031-2 $0.98 Add To Cart 035 MAKITA HEX. SOCKET HEAD BOLT M4X12 FOR 4340CT P/N:265353-6 Part No.: 265353-6 $0.44 Add To Cart 036 MAKITA INSULATION COVER FOR JR188D P/N:422221-8 Part No.: 422221-8 $6.43 Add To Cart 037 MAKITA SHOE FOR JR188D P/N:161795-1 Part No.: 161795-1 $5.45 Add To Cart 038 MAKITA HEX.SOCKET HEAD BOLT M6X14 FOR JR3070CT P/N:265531-8 Part No.: 265531-8 $0.55 Add To Cart 040 MAKITA RETAINING RING S-10 FOR HR3000C HR2810 P/N:961006-2 Part No.: 961006-2 $0.33 Add To Cart 043 MAKITA HEX. SOCKET HEAD BOLT M4X12 FOR 4340CT P/N:265353-6 Part No.: 265353-6 $0.44 Add To Cart 044 MAKITA ROTOR ASS'Y FOR DJR188 P/N:519457-9 Part No.: 519457-9 $30.96 Add To Cart 046 MAKITA STATOR FOR DJR188 P/N:629292-8 Part No.: 629292-8 $12.21 Add To Cart 047 MAKITA FLAT HEAD SCREW M3X6 P/N:652069-6 Part No.: 652069-6 $0.22 Add To Cart 048 MAKITA CONTROLLER B FOR DJR188 P/N:620760-4 Part No.: 620760-4 $19.95 Add To Cart 049 MAKITA TAPPING SCREW PT 2X6 FOR DDF083 P/N:266490-9 Part No.: 266490-9 $0.33 Add To Cart 050 MAKITA TAPPING SCREW PT M3X16 P/N:266429-2 Part No.: 266429-2 $0.22 Add To Cart 051 MAKITA MOTOR HOUSING SET FOR DJR188 P/N:183H44-4 Part No.: 183H44-4 $3.38 Add To Cart 052 MAKITA P.H. SCREW M4X18 WITH WRM FOR PK5001C P/N:911531-3 Part No.: 911531-3 $0.33 Add To Cart 053 MAKITA MOTOR HOUSING SET FOR DJR188 P/N:183H44-4 Part No.: 183H44-4 $3.38 Add To Cart 056 MAKITA HANDLE SET COMPLETE FOR JR188D P/N:183H42-8 Part No.: 183H42-8 $17.33 Add To Cart 057 MAKITA LOCK OFF BUTTON FOR JR188D P/N:458114-3 Part No.: 458114-3 $0.44 Add To Cart 058 MAKITA CUSHION P/N:424517-3 Part No.: 424517-3 $0.44 Add To Cart 060 MAKITA SWITCH C3JW-4B FOR DDF/DHP484 P/N:650710-5 Part No.: 650710-5 $18.53 Add To Cart 061 MAKITA TERMINAL FOR DTP/DDF/DHP484 P/N:643874-2 Part No.: 643874-2 $3.92 Add To Cart 062 MAKITA CONTROLLER A FOR DJR188 P/N:620759-9 Part No.: 620759-9 $94.94 Add To Cart 064 MAKITA HANDLE SET COMPLETE FOR JR188D P/N:183H42-8 Part No.: 183H42-8 $17.33 Add To Cart 065 MAKITA SLIDER ASSEMBLY FOR JR188D P/N:126722-5 Part No.: 126722-5 $32.26 Add To Cart

Brand: Makita

Specifications:

• Ref. No.: Part Name & Number
• 001: MAKITA PROTECTOR FOR DJR188 P/N:422223-4 Part No.: 422223-4
• 002: MAKITA DRIVING SLEEVE FOR DC/AC-JR P/N:310848-5 Part No.: 310848-5
• 004: MAKITA PIN 3 FOR DC/AC-JR P/N:268094-3 Part No.: 268094-3
• 006: MAKITA SPRING 6 FOR DC/AC-JR P/N:234381-2 Part No.: 234381-2
• 007: MAKITA SHOULDER PIN 5 FOR JR3070CT P/N:256569-4 Part No.: 256569-4
• 008: MAKITA CONNECTING SLEEVE FOR JR188D P/N:458113-5 Part No.: 458113-5
• 009: MAKITA PUSH PIN FOR JR100D P/N:310859-0 Part No.: 310859-0
• 010: MAKITA COMPRESSION SPRING FOR 6702D Part No.: 233025-1
• 011: MAKITA TOPSION SPRING 17 FOR DC-JR P/N:233594-2 Part No.: 233594-2
• 014: MAKITA SLIDER FOR JR188D P/N:161796-9 Part No.: 161796-9
• 015: MAKITA ROLLER FOR JR187D P/N:310663-7 Part No.: 310663-7
• 016: MAKITA PIN 6 FOR JR3061T P/N:268341-2 Part No.: 268341-2
• 019: MAKITA PAN HEAD SCREW M4X16 P/N:911128-8 Part No.: 911128-8
• 020: MAKITA GEAR HOUSING R FOR DJR188D P/N:144809-1 Part No.: 144809-1
• 021: MAKITA ROD GUIDE R FOR JR188D P/N:347303-4 Part No.: 347303-4
• 022: MAKITA HEX. SOCKET HEAD BOLT M4X12 FOR 4340CT P/N:265353-6 Part No.: 265353-6
• 023: MAKITA SHOULDER PIN 6-8 FOR DJR18* P/N:256567-8 Part No.: 256567-8
• 025: MAKITA GEAR COMPLETE FOR JR188D P/N:144806-7 Part No.: 144806-7
• 026: MAKITA HEX. SOCKET HEAD BOLT M4X12 FOR 4340CT P/N:265353-6 Part No.: 265353-6
• 027: MAKITA ROD GUIDE L FOR JR188D P/N:347302-6 Part No.: 347302-6
• 028: MAKITA SEAL RING FOR JR188D P/N:422224-2 Part No.: 422224-2
• 029: MAKITA FLAT WASHER 45 FOR HR4001C Part No.: 267336-2
• 030: MAKITA GEAR HOUSING L FOR DJR188D P/N:144808-3 Part No.: 144808-3
• 032: MAKITA FLAT WASHER 4 FOR JR188D P/N:253400-5 Part No.: 253400-5
• 033: MAKITA HEX. SOCKET HEAD BOLT M4X12 FOR 4340CT P/N:265353-6 Part No.: 265353-6
• 034: MAKITA BEARING RETAINER 51 FOR JR188D P/N:285031-2 Part No.: 285031-2
• 035: MAKITA HEX. SOCKET HEAD BOLT M4X12 FOR 4340CT P/N:265353-6 Part No.: 265353-6
• 036: MAKITA INSULATION COVER FOR JR188D P/N:422221-8 Part No.: 422221-8
• 037: MAKITA SHOE FOR JR188D P/N:161795-1 Part No.: 161795-1
• 038: MAKITA HEX.SOCKET HEAD BOLT M6X14 FOR JR3070CT P/N:265531-8 Part No.: 265531-8
• 040: MAKITA RETAINING RING S-10 FOR HR3000C HR2810 P/N:961006-2 Part No.: 961006-2
• 043: MAKITA HEX. SOCKET HEAD BOLT M4X12 FOR 4340CT P/N:265353-6 Part No.: 265353-6
• 044: MAKITA ROTOR ASS'Y FOR DJR188 P/N:519457-9 Part No.: 519457-9
• 046: MAKITA STATOR FOR DJR188 P/N:629292-8 Part No.: 629292-8
• 047: MAKITA FLAT HEAD SCREW M3X6 P/N:652069-6 Part No.: 652069-6
• 048: MAKITA CONTROLLER B FOR DJR188 P/N:620760-4 Part No.: 620760-4
• 049: MAKITA TAPPING SCREW PT 2X6 FOR DDF083 P/N:266490-9 Part No.: 266490-9
• 050: MAKITA TAPPING SCREW PT M3X16 P/N:266429-2 Part No.: 266429-2
• 051: MAKITA MOTOR HOUSING SET FOR DJR188 P/N:183H44-4 Part No.: 183H44-4
