MAKITA DTD173 CORDLESS IMPACT DRIVER SPARE PARTS

Spare Parts of Makita DTD173 Cordless Impact Driver Ref. No. Part Name & Number Price 002 MAKITA HOUSING SET FOR DTD173 P/N:183X60-2 Part No.: 183X60-2 $17.44 Add To Cart 003 MAKITA TAPPING SCREW PT M3X16 P/N:266429-2 Part No.: 266429-2 $0.22 Add To Cart 004 MAKITA RING SPRING 12 FOR WR100D P/N:231952-6 Part No.: 231952-6 $1.53 Add To Cart 005 MAKITA FLAT WASHER 13 FOR TD003G P/N:253575-0 Part No.: 253575-0 $0.22 Add To Cart 006 MAKITA SPRING 14 FOR TD001G P/N:232592-3 Part No.: 232592-3 $0.33 Add To Cart 007 MAKITA BIT SLEEVE P/N:327B23-8 Part No.: 327B23-8 $1.96 Add To Cart 008 MAKITA LEAF SPRING TD003G P/N:232800-2 Part No.: 232800-2 $0.44 Add To Cart 009 MAKITA STEEL BALL 3.5 FOR TD146D P/N:216040-0 Part No.: 216040-0 $0.11 Add To Cart 010 MAKITA FLAT WASHER 13 FOR TD003G P/N:253575-0 Part No.: 253575-0 $0.22 Add To Cart 011 MAKITA LED CIRCUIT FOR DTD173 P/N:620L50-7 Part No.: 620L50-7 $24.09 Add To Cart 012 MAKITA HAMMER CASE COVER FOR DTD173 P/N:413P70-0 Part No.: 413P70-0 $0.87 Add To Cart 013 MAKITA SPONGE SHEET FOR DTD173 P/N:422A14-9 Part No.: 422A14-9 $0.33 Add To Cart 014 MAKITA HAMMER CASE COMPLETE FOR DTD173 P/N:141P11-3 Part No.: 141P11-3 $25.07 Add To Cart 015 MAKITA O RING 12.5 P/N:213166-9 Part No.: 213166-9 $0.33 Add To Cart 016 MAKITA ANVIL N ASSEMBLY FOR DTD173 P/N:136888-3 Part No.: 136888-3 $20.60 Add To Cart 017 MAKITA HAMMER FOR DTD173 P/N:327B72-5 Part No.: 327B72-5 $17.66 Add To Cart 018 MAKITA STEEL BALL 3.5 FOR TD146D P/N:216040-0 Part No.: 216040-0 $0.11 Add To Cart 019 MAKITA FLAT WASHER 24 P/N:267175-0 Part No.: 267175-0 $0.33 Add To Cart 020 MAKITA COMPRESSION SPRING 24B P/N:232459-5 Part No.: 232459-5 $2.83 Add To Cart 021 MAKITA SPUR GEAR 22 FOR DTD172 P/N:227350-0 Part No.: 227350-0 $2.18 Add To Cart 022 MAKITA STEEL BALL 5.6 FOR HK1800 P/N : 216011-7 Part No.: 216011-7 $0.11 Add To Cart 023 MAKITA SPINDLE FOR DTD173 P/N:327B71-7 Part No.: 327B71-7 $45.02 Add To Cart 024 MAKITA PIN 5 FOR DC-TD/TW P/N:268311-1 Part No.: 268311-1 $0.76 Add To Cart 026 MAKITA SEAL FOR DTD172 P/N:422688-0 Part No.: 422688-0 $0.65 Add To Cart 027 MAKITA INTERNAL GEAR 51 FOR DTD172 P/N:227882-7 Part No.: 227882-7 $6.00 Add To Cart 028 MAKITA O RING 46 FOR 5008MG P/N:213623-7 Part No.: 213623-7 $0.33 Add To Cart 029 MAKITA BEARING BOX COMPLETE FOR DTD173 P/N:141P12-1 Part No.: 141P12-1 $10.25 Add To Cart 030 MAKITA TAPPING SCREW PT 2X6 FOR DDF083 P/N:266490-9 Part No.: 266490-9 $0.33 Add To Cart 031 MAKITA FLAT HEAD SCREW M3X6 P/N:652069-6 Part No.: 652069-6 $0.22 Add To Cart 032 MAKITA STATOR FOR DTD154 P/N:629217-2 Part No.: 629217-2 $10.25 Add To Cart 033 MAKITA CONTROLLER ASS'Y FOR DTD173 P/N:539261-0 Part No.: 539261-0 $126.11 Add To Cart 034 MAKITA ROTOR FOR DTD172 P/N:619678-4 Part No.: 619678-4 $51.45 Add To Cart 035 MAKITA REAR COVER FOR DTD173 P/N:413P71-8 Part No.: 413P71-8 $1.74 Add To Cart 036 MAKITA TAPPING SCREW PT M3X16 P/N:266429-2 Part No.: 266429-2 $0.22 Add To Cart 038 MAKITA SWITCH UNIT FOR DTD173 P/N:632U37-1 Part No.: 632U37-1 $9.70 Add To Cart 039 MAKITA F/R CHANGE LEVER FOR DTD173 P/N:413P74-2 Part No.: 413P74-2 $0.55 Add To Cart 040 MAKITA SWITCH C3JR-1A-1 FOR DC-TD/TW P/N:651442-7 Part No.: 651442-7 $17.44 Add To Cart 041 MAKITA TERMINAL FOR DTP/DDF/DHP484 P/N:643874-2 Part No.: 643874-2 $3.92 Add To Cart 042 MAKITA HOUSING SET FOR DTD173 P/N:183X60-2 Part No.: 183X60-2 $17.44 Add To Cart

Brand: Makita

Specifications:

• Ref. No.: Part Name & Number
• 002: MAKITA HOUSING SET FOR DTD173 P/N:183X60-2 Part No.: 183X60-2
• 003: MAKITA TAPPING SCREW PT M3X16 P/N:266429-2 Part No.: 266429-2
• 004: MAKITA RING SPRING 12 FOR WR100D P/N:231952-6 Part No.: 231952-6
• 005: MAKITA FLAT WASHER 13 FOR TD003G P/N:253575-0 Part No.: 253575-0
• 006: MAKITA SPRING 14 FOR TD001G P/N:232592-3 Part No.: 232592-3
• 007: MAKITA BIT SLEEVE P/N:327B23-8 Part No.: 327B23-8
• 008: MAKITA LEAF SPRING TD003G P/N:232800-2 Part No.: 232800-2
• 009: MAKITA STEEL BALL 3.5 FOR TD146D P/N:216040-0 Part No.: 216040-0
• 010: MAKITA FLAT WASHER 13 FOR TD003G P/N:253575-0 Part No.: 253575-0
• 011: MAKITA LED CIRCUIT FOR DTD173 P/N:620L50-7 Part No.: 620L50-7
• 012: MAKITA HAMMER CASE COVER FOR DTD173 P/N:413P70-0 Part No.: 413P70-0
• 013: MAKITA SPONGE SHEET FOR DTD173 P/N:422A14-9 Part No.: 422A14-9
• 014: MAKITA HAMMER CASE COMPLETE FOR DTD173 P/N:141P11-3 Part No.: 141P11-3
• 015: MAKITA O RING 12.5 P/N:213166-9 Part No.: 213166-9
• 016: MAKITA ANVIL N ASSEMBLY FOR DTD173 P/N:136888-3 Part No.: 136888-3
• 017: MAKITA HAMMER FOR DTD173 P/N:327B72-5 Part No.: 327B72-5
• 018: MAKITA STEEL BALL 3.5 FOR TD146D P/N:216040-0 Part No.: 216040-0
• 019: MAKITA FLAT WASHER 24 P/N:267175-0 Part No.: 267175-0
• 020: MAKITA COMPRESSION SPRING 24B P/N:232459-5 Part No.: 232459-5
• 021: MAKITA SPUR GEAR 22 FOR DTD172 P/N:227350-0 Part No.: 227350-0
• 022: MAKITA STEEL BALL 5.6 FOR HK1800 P/N : 216011-7 Part No.: 216011-7
• 023: MAKITA SPINDLE FOR DTD173 P/N:327B71-7 Part No.: 327B71-7
• 024: MAKITA PIN 5 FOR DC-TD/TW P/N:268311-1 Part No.: 268311-1
• 026: MAKITA SEAL FOR DTD172 P/N:422688-0 Part No.: 422688-0
• 027: MAKITA INTERNAL GEAR 51 FOR DTD172 P/N:227882-7 Part No.: 227882-7
• 028: MAKITA O RING 46 FOR 5008MG P/N:213623-7 Part No.: 213623-7
• 029: MAKITA BEARING BOX COMPLETE FOR DTD173 P/N:141P12-1 Part No.: 141P12-1
• 030: MAKITA TAPPING SCREW PT 2X6 FOR DDF083 P/N:266490-9 Part No.: 266490-9
• 031: MAKITA FLAT HEAD SCREW M3X6 P/N:652069-6 Part No.: 652069-6
• 032: MAKITA STATOR FOR DTD154 P/N:629217-2 Part No.: 629217-2
• 033: MAKITA CONTROLLER ASS'Y FOR DTD173 P/N:539261-0 Part No.: 539261-0
• 034: MAKITA ROTOR FOR DTD172 P/N:619678-4 Part No.: 619678-4
• 035: MAKITA REAR COVER FOR DTD173 P/N:413P71-8 Part No.: 413P71-8
• 036: MAKITA TAPPING SCREW PT M3X16 P/N:266429-2 Part No.: 266429-2
• 038: MAKITA SWITCH UNIT FOR DTD173 P/N:632U37-1 Part No.: 632U37-1
• 039: MAKITA F/R CHANGE LEVER FOR DTD173 P/N:413P74-2 Part No.: 413P74-2
• 040: MAKITA SWITCH C3JR-1A-1 FOR DC-TD/TW P/N:651442-7 Part No.: 651442-7
• 041: MAKITA TERMINAL FOR DTP/DDF/DHP484 P/N:643874-2 Part No.: 643874-2
• 042: MAKITA HOUSING SET FOR DTD173 P/N:183X60-2 Part No.: 183X60-2
