MAKITA DTD154 CORDLESS IMPACT DRIVER SPARE PARTS

Spare Parts of Makita DTD154 Cordless Imapact Driver Ref. No. Part Name & Number Price 001 MAKITA HOUSING SET FOR DTD154 P/N:183E36-5 Part No.: 183E36-5 $15.59 Add To Cart 003 MAKITA TAPPING SCREW PT M3X16 P/N:266429-2 Part No.: 266429-2 $0.22 Add To Cart 004 MAKITA F/R CHANGE LEVER FOR DC-TD/TW P/N:455053-8 Part No.: 455053-8 $0.55 Add To Cart 005 MAKITA SWITCH COMPLETE FOR DTD154 P/N:143975-1 Part No.: 143975-1 $17.99 Add To Cart 006 MAKITA ROTOR FOR DTD154 P/N:619408-3 Part No.: 619408-3 $44.80 Add To Cart 007 MAKITA STATOR FOR DTD154 P/N:629217-2 Part No.: 629217-2 $10.25 Add To Cart 008 MAKITA LED CIRCUIT FOR TD153D P/N:620557-1 Part No.: 620557-1 $7.09 Add To Cart 009 MAKITA TERMINAL P/N:643860-3 Part No.: 643860-3 $3.49 Add To Cart 010 MAKITA RING SPRING 11 FOR BTD120 6903VD P/N:231951-8 Part No.: 231951-8 $0.33 Add To Cart 011 MAKITA FLAT WASHER 12 FOR BTD120 6903VD P/N:267085-1 Part No.: 267085-1 $0.33 Add To Cart 012 MAKITA COMPRESSION SPRING 13 FOR BTD120 6903VD P/N:233005-7 Part No.: 233005-7 $0.11 Add To Cart 013 MAKITA BIT SLEEVE FOR TD134D P/N:326072-0 Part No.: 326072-0 $2.18 Add To Cart 014 MAKITA BUMPER FOR DTD154 P/N:424873-1 Part No.: 424873-1 $0.65 Add To Cart 016 MAKITA HAMMER CASE COMPLETE FOR DTD154 P/N:143951-5 Part No.: 143951-5 $13.84 Add To Cart 017 MAKITA NYLON WASHER 24 FOR DTD148 P/N:261155-8 Part No.: 261155-8 $0.55 Add To Cart 018 MAKITA STEEL BALL 3.5 FOR 6409 P/N : 216001-0 Part No.: 216001-0 $0.11 Add To Cart 019 MAKITA ANVIL N FOR TD137D P/N:326507-1 Part No.: 326507-1 $9.27 Add To Cart 021 MAKITA STEEL BALL 3.5 FOR 6409 P/N : 216001-0 Part No.: 216001-0 $0.11 Add To Cart 022 MAKITA FLAT WASHER 24 P/N:267175-0 Part No.: 267175-0 $0.33 Add To Cart 023 MAKITA COMPRESSION SPRING 24 FOR DTD148 P/N:234331-7 Part No.: 234331-7 $3.05 Add To Cart 025 MAKITA STEEL BALL 5.6 FOR TD146D P/N:216041-8 Part No.: 216041-8 $0.22 Add To Cart 026 MAKITA SPUR GEAR 22 FOR DTW281 P/N:227338-0 Part No.: 227338-0 $2.94 Add To Cart 027 MAKITA SPINDLE FOR DTD154 P/N:326783-7 Part No.: 326783-7 $17.77 Add To Cart 028 MAKITA PIN 5 FOR DC-TD/TW P/N:268311-1 Part No.: 268311-1 $0.76 Add To Cart 029 MAKITA THIN WASHER 15 FOR HR4000C P/N:253314-8 Part No.: 253314-8 $0.55 Add To Cart 030 MAKITA INTERNAL GEAR 51 FOR DTD154 P/N:221457-4 Part No.: 221457-4 $1.64 Add To Cart 032 MAKITA O RING 40 FOR HR3520 P/N:213507-9 Part No.: 213507-9 $0.33 Add To Cart 033 MAKITA BEARING BOX COMPLETE FOR DTD154 P/N:143976-9 Part No.: 143976-9 $6.54 Add To Cart 035 MAKITA HOUSING SET FOR DTD154 P/N:183E36-5 Part No.: 183E36-5 $15.59 Add To Cart 036 MAKITA SWITCH PLATE COMPLETE FOR DTD154 P/N:143954-9 Part No.: 143954-9 $2.07 Add To Cart 037 MAKITA REAR COVER FOR DTD154 P/N:457069-9 Part No.: 457069-9 $2.73 Add To Cart 038 MAKITA TAPPING SCREW PT M3X16 P/N:266429-2 Part No.: 266429-2 $0.22 Add To Cart 039 MAKITA TAPPING SCREW PT 2X6 FOR DDF083 P/N:266490-9 Part No.: 266490-9 $0.33 Add To Cart 040 MAKITA FLAT HEAD SCREW M3X6 P/N:652069-6 Part No.: 652069-6 $0.22 Add To Cart 041 MAKITA CONTROLLER FOR DTD154 P/N:620564-4 Part No.: 620564-4 $91.89 Add To Cart

Brand: Makita

Specifications:

• Ref. No.: Part Name & Number
• 001: MAKITA HOUSING SET FOR DTD154 P/N:183E36-5 Part No.: 183E36-5
• 003: MAKITA TAPPING SCREW PT M3X16 P/N:266429-2 Part No.: 266429-2
• 004: MAKITA F/R CHANGE LEVER FOR DC-TD/TW P/N:455053-8 Part No.: 455053-8
• 005: MAKITA SWITCH COMPLETE FOR DTD154 P/N:143975-1 Part No.: 143975-1
• 006: MAKITA ROTOR FOR DTD154 P/N:619408-3 Part No.: 619408-3
• 007: MAKITA STATOR FOR DTD154 P/N:629217-2 Part No.: 629217-2
• 008: MAKITA LED CIRCUIT FOR TD153D P/N:620557-1 Part No.: 620557-1
• 009: MAKITA TERMINAL P/N:643860-3 Part No.: 643860-3
• 010: MAKITA RING SPRING 11 FOR BTD120 6903VD P/N:231951-8 Part No.: 231951-8
• 011: MAKITA FLAT WASHER 12 FOR BTD120 6903VD P/N:267085-1 Part No.: 267085-1
• 012: MAKITA COMPRESSION SPRING 13 FOR BTD120 6903VD P/N:233005-7 Part No.: 233005-7
• 013: MAKITA BIT SLEEVE FOR TD134D P/N:326072-0 Part No.: 326072-0
• 014: MAKITA BUMPER FOR DTD154 P/N:424873-1 Part No.: 424873-1
• 016: MAKITA HAMMER CASE COMPLETE FOR DTD154 P/N:143951-5 Part No.: 143951-5
• 017: MAKITA NYLON WASHER 24 FOR DTD148 P/N:261155-8 Part No.: 261155-8
• 018: MAKITA STEEL BALL 3.5 FOR 6409 P/N : 216001-0 Part No.: 216001-0
• 019: MAKITA ANVIL N FOR TD137D P/N:326507-1 Part No.: 326507-1
• 021: MAKITA STEEL BALL 3.5 FOR 6409 P/N : 216001-0 Part No.: 216001-0
• 022: MAKITA FLAT WASHER 24 P/N:267175-0 Part No.: 267175-0
• 023: MAKITA COMPRESSION SPRING 24 FOR DTD148 P/N:234331-7 Part No.: 234331-7
• 025: MAKITA STEEL BALL 5.6 FOR TD146D P/N:216041-8 Part No.: 216041-8
• 026: MAKITA SPUR GEAR 22 FOR DTW281 P/N:227338-0 Part No.: 227338-0
• 027: MAKITA SPINDLE FOR DTD154 P/N:326783-7 Part No.: 326783-7
• 028: MAKITA PIN 5 FOR DC-TD/TW P/N:268311-1 Part No.: 268311-1
• 029: MAKITA THIN WASHER 15 FOR HR4000C P/N:253314-8 Part No.: 253314-8
• 030: MAKITA INTERNAL GEAR 51 FOR DTD154 P/N:221457-4 Part No.: 221457-4
• 032: MAKITA O RING 40 FOR HR3520 P/N:213507-9 Part No.: 213507-9
• 033: MAKITA BEARING BOX COMPLETE FOR DTD154 P/N:143976-9 Part No.: 143976-9
• 035: MAKITA HOUSING SET FOR DTD154 P/N:183E36-5 Part No.: 183E36-5
• 036: MAKITA SWITCH PLATE COMPLETE FOR DTD154 P/N:143954-9 Part No.: 143954-9
• 037: MAKITA REAR COVER FOR DTD154 P/N:457069-9 Part No.: 457069-9
• 038: MAKITA TAPPING SCREW PT M3X16 P/N:266429-2 Part No.: 266429-2
• 039: MAKITA TAPPING SCREW PT 2X6 FOR DDF083 P/N:266490-9 Part No.: 266490-9
• 040: MAKITA FLAT HEAD SCREW M3X6 P/N:652069-6 Part No.: 652069-6
• 041: MAKITA CONTROLLER FOR DTD154 P/N:620564-4 Part No.: 620564-4
