MAKITA DPB184 CORDLESS PORTABLE BAND SAW SPARE PARTS

Spare Parts of Makita DPB184 Portable Band Saw Ref. No. Part Name & Number Price 001 MAKITA MOTOR HOUSING SET FOR DPB184 P/N:183P68-8 Part No.: 183P68-8 $5.67 Add To Cart 002 MAKITA TAPPING SCREW BIND PT 3X16 FOR 6226DWE P/N:266130-9 Part No.: 266130-9 $0.11 Add To Cart 003 MAKITA PAN HEAD SCREW M4X60 FOR 6510LVR P/N:911188-0 Part No.: 911188-0 $0.55 Add To Cart 005 MAKITA MOTOR HOUSING SET FOR DPB184 P/N:183P68-8 Part No.: 183P68-8 $5.67 Add To Cart 006 MAKITA STATOR FOR DPB183/184 P/N:629482-3 Part No.: 629482-3 $14.28 Add To Cart 007 MAKITA ROTOR ASS'Y FOR DPB183/184 P/N:619628-9 Part No.: 619628-9 $50.14 Add To Cart 008 MAKITA LOCK WASHER P/N:253474-6 Part No.: 253474-6 $0.44 Add To Cart 009 MAKITA SPUR GEAR 13 P/N:226923-6 Part No.: 226923-6 $0.55 Add To Cart 010 MAKITA SPUR GEAR 14B COMPLETE P/N:140M80-3 Part No.: 140M80-3 $2.07 Add To Cart 011 MAKITA SPUR GEAR 13 P/N:226923-6 Part No.: 226923-6 $0.55 Add To Cart 012 MAKITA SPUR GEAR 16 COMPLETE P/N:140M81-1 Part No.: 140M81-1 $2.51 Add To Cart 013 MAKITA SPUR GEAR 11 P/N:226924-4 Part No.: 226924-4 $0.65 Add To Cart 014 MAKITA SPINDLE COMPLETE P/N:140T74-0 Part No.: 140T74-0 $16.90 Add To Cart 015 MAKITA BALL BEARING 6002DW FOR GA5010 P/N:211247-3 Part No.: 211247-3 $1.85 Add To Cart 017 MAKITA GEAR HOUSING FOR DPB183/184 P/N:319980-2 Part No.: 319980-2 $10.57 Add To Cart 018 MAKITA BALL BEARING 6002DW FOR GA5010 P/N:211247-3 Part No.: 211247-3 $1.85 Add To Cart 022 MAKITA INTERNAL GEAR 40 P/N:226921-0 Part No.: 226921-0 $4.03 Add To Cart 023 MAKITA PAN HEAD SCREW M4X20 P/N:911138-5 Part No.: 911138-5 $0.33 Add To Cart 024 MAKITA HANDLE SET P/N:183R22-4 Part No.: 183R22-4 $43.49 Add To Cart 025 MAKITA INTERNAL GEAR 39 P/N:226922-8 Part No.: 226922-8 $2.40 Add To Cart 029 MAKITA SWITCH FOR DPB184/PB002G P/N:651486-7 Part No.: 651486-7 $23.76 Add To Cart 030 MAKITA LOCK OFF BUTTON P/N:412551-5 Part No.: 412551-5 $1.53 Add To Cart 031 MAKITA LED CIRCUIT FOR TD160D P/N:620521-2 Part No.: 620521-2 $7.19 Add To Cart 033 MAKITA CONTROLLER FOR DPB184 P/N:620D05-4 Part No.: 620D05-4 $170.91 Add To Cart 034 MAKITA TERMINAL FOR DTP/DDF/DHP484 P/N:643874-2 Part No.: 643874-2 $3.92 Add To Cart 035 MAKITA TAPPING SCREW BIND PT 3X16 FOR 6226DWE P/N:266130-9 Part No.: 266130-9 $0.11 Add To Cart 036 MAKITA STOP RING E-3 FOR 4304 P/N:961017-7 Part No.: 961017-7 $0.11 Add To Cart 037 MAKITA PIN 4 FOR 3901 P/N:256689-4 Part No.: 256689-4 $1.85 Add To Cart 038 MAKITA WHEEL COVER P/N:412550-7 Part No.: 412550-7 $9.92 Add To Cart 039 MAKITA RING SPRING 12 FOR N5900B Part No.: 231955-0 $0.33 Add To Cart 040 MAKITA LEVER 54 P/N:271462-1 Part No.: 271462-1 $1.64 Add To Cart 041 MAKITA PAN HEAD SCREW M4X20 P/N:911138-5 Part No.: 911138-5 $0.33 Add To Cart 042 MAKITA LEVER HOLDER P/N:459084-9 Part No.: 459084-9 $1.85 Add To Cart 045 MAKITA FRAME COMPLETE P/N:140V76-8 Part No.: 140V76-8 $49.70 Add To Cart 047 MAKITA STOPPER PLATE P/N:347696-9 Part No.: 347696-9 $3.05 Add To Cart 048 MAKITA FLAT WASHER 5 FOR JS1670 P/N:267010-2 Part No.: 267010-2 $0.33 Add To Cart 049 MAKITA NEEDLE BEARING 510 P/N:212199-1 Part No.: 212199-1 $3.60 Add To Cart 051 MAKITA PIN 5 FOR JS1670 P/N:256155-1 Part No.: 256155-1 $0.55 Add To Cart 052 MAKITA PAN HEAD SCREW M4X20 P/N:911138-5 Part No.: 911138-5 $0.33 Add To Cart 054 MAKITA SLIDE PLATE P/N:162564-3 Part No.: 162564-3 $6.43 Add To Cart 055 MAKITA FLAT WASHER 15 FOR HP2040 P/N:267164-5 Part No.: 267164-5 $0.33 Add To Cart 056 MAKITA PIN 6 P/N:268241-6 Part No.: 268241-6 $0.87 Add To Cart 057 MAKITA PAN HEAD SCREW M4X20 P/N:911138-5 Part No.: 911138-5 $0.33 Add To Cart 058 MAKITA RUBBER TIRE FOR PB181D P/N:424589-8 Part No.: 424589-8 $1.42 Add To Cart 059 MAKITA WHEEL COMPLETE A FOR DPB182 P/N:140J07-5 Part No.: 140J07-5 $13.41 Add To Cart 062 MAKITA FLAT WASHER 6 P/N:267173-4 Part No.: 267173-4 $0.87 Add To Cart 063 MAKITA RUBBER TIRE FOR PB181D P/N:424589-8 Part No.: 424589-8 $1.42 Add To Cart 064 MAKITA WHEEL B P/N:459087-3 Part No.: 459087-3 $7.63 Add To Cart 067 MAKITA FLAT WASHER 6 P/N:267173-4 Part No.: 267173-4 $0.87 Add To Cart 068 MAKITA '+ PAN HEAD SCREW M5 FOR BPB180 P/N:251337-0 Part No.: 251337-0 $0.87 Add To Cart 069 MAKITA BALL BEARING 696ZZ P/N:210187-2 Part No.: 210187-2 $0.87 Add To Cart 070 MAKITA FLAT WASHER 6 FOR HM1302 P/N:941152-7 Part No.: 941152-7 $0.11 Add To Cart 071 MAKITA BALL BEARING 696ZZ P/N:210187-2 Part No.: 210187-2 $0.87 Add To Cart 072 MAKITA '+ PAN HEAD SCREW M5 FOR BPB180 P/N:251337-0 Part No.: 251337-0 $0.87 Add To Cart 073 MAKITA BALL BEARING 696ZZ P/N:210187-2 Part No.: 210187-2 $0.87 Add To Cart 074 MAKITA FLAT WASHER 6 FOR HM1302 P/N:941152-7 Part No.: 941152-7 $0.11 Add To Cart 075 MAKITA BALL BEARING 696ZZ P/N:210187-2 Part No.: 210187-2 $0.87 Add To Cart 076 MAKITA UPPER HOLDER P/N:319993-3 Part No.: 319993-3 $4.58 Add To Cart 077 MAKITA PAN HEAD SCREW M4X20 P/N:911138-5 Part No.: 911138-5 $0.33 Add To Cart 078 MAKITA PIN 6 FOR BTW201 / 6905B P/N:256033-5 Part No.: 256033-5 $0.65 Add To Cart 079 MAKITA BALL BEARING 696ZZ P/N:210187-2 Part No.: 210187-2 $0.87 Add To Cart 080 MAKITA BALL BEARING 696ZZ P/N:210187-2 Part No.: 210187-2 $0.87 Add To Cart 081 MAKITA FLAT WASHER 6 FOR HM1302 P/N:941152-7 Part No.: 941152-7 $0.11 Add To Cart 082 MAKITA BALL BEARING 696ZZ P/N:210187-2 Part No.: 210187-2 $0.87 Add To Cart 083 MAKITA '+ PAN HEAD SCREW M5 FOR BPB180 P/N:251337-0 Part No.: 251337-0 $0.87 Add To Cart 084 MAKITA '+ PAN HEAD SCREW M5 FOR BPB180 P/N:251337-0 Part No.: 251337-0 $0.87 Add To Cart 085 MAKITA BALL BEARING 696ZZ P/N:210187-2 Part No.: 210187-2 $0.87 Add To Cart 086 MAKITA FLAT WASHER 6 FOR HM1302 P/N:941152-7 Part No.: 941152-7 $0.11 Add To Cart 087 MAKITA BALL BEARING 696ZZ P/N:210187-2 Part No.: 210187-2 $0.87 Add To Cart 088 MAKITA PIN 6 FOR BTW201 / 6905B P/N:256033-5 Part No.: 256033-5 $0.65 Add To Cart 089 MAKITA BALL BEARING 696ZZ P/N:210187-2 Part No.: 210187-2 $0.87 Add To Cart 090 MAKITA PAN HEAD SCREW M4X20 P/N:911138-5 Part No.: 911138-5 $0.33 Add To Cart 091 MAKITA LOWER HOLDER P/N:319992-5 Part No.: 319992-5 $4.58 Add To Cart 092 MAKITA HOOK P/N:162815-4 Part No.: 162815-4 $1.64 Add To Cart 093 MAKITA COMPRESSION SPRING 4 FOR 6019DWE P/N:231433-0 Part No.: 231433-0 $0.22 Add To Cart 094 MAKITA FLAT HEAD SCREW M3X6 P/N:652069-6 Part No.: 652069-6 $0.22 Add To Cart 098 MAKITA HOOK P/N:162815-4 Part No.: 162815-4 $1.64 Add To Cart 099 MAKITA TAPPING SCREW PT 2X6 FOR DDF083 P/N:266490-9 Part No.: 266490-9 $0.33 Add To Cart 100 MAKITA PAN HEAD SCREW M5X16 FOR LS1040 P/N:911223-4 Part No.: 911223-4 $0.33 Add To Cart 101 MAKITA HOOK ASSEMBLY P/N:127601-0 Part No.: 127601-0 $8.61 Add To Cart 106 MAKITA SPRING PIN 3-12 FOR 906 P/N:951057-3 Part No.: 951057-3 $0.33 Add To Cart 107 MAKITA GUARD P/N:327638-9 Part No.: 327638-9 $24.74 Add To Cart 108 MAKITA FLAT WASHER 5 FOR 4100NH P/N:941102-2 Part No.: 941102-2 $0.22 Add To Cart 109 MAKITA TOOTHED LOCK WASHER 5 P/N:253484-3 Part No.: 253484-3 $0.22 Add To Cart 110 MAKITA HEX.LOCK NUT M5-8 FOR UH4570 P/N:264013-7 Part No.: 264013-7 $0.33 Add To Cart

Brand: Makita

Specifications:

• Ref. No.: Part Name & Number
• 001: MAKITA MOTOR HOUSING SET FOR DPB184 P/N:183P68-8 Part No.: 183P68-8
• 002: MAKITA TAPPING SCREW BIND PT 3X16 FOR 6226DWE P/N:266130-9 Part No.: 266130-9
• 003: MAKITA PAN HEAD SCREW M4X60 FOR 6510LVR P/N:911188-0 Part No.: 911188-0
• 005: MAKITA MOTOR HOUSING SET FOR DPB184 P/N:183P68-8 Part No.: 183P68-8
• 006: MAKITA STATOR FOR DPB183/184 P/N:629482-3 Part No.: 629482-3
• 007: MAKITA ROTOR ASS'Y FOR DPB183/184 P/N:619628-9 Part No.: 619628-9
• 008: MAKITA LOCK WASHER P/N:253474-6 Part No.: 253474-6
• 009: MAKITA SPUR GEAR 13 P/N:226923-6 Part No.: 226923-6
• 010: MAKITA SPUR GEAR 14B COMPLETE P/N:140M80-3 Part No.: 140M80-3
• 011: MAKITA SPUR GEAR 13 P/N:226923-6 Part No.: 226923-6
• 012: MAKITA SPUR GEAR 16 COMPLETE P/N:140M81-1 Part No.: 140M81-1
• 013: MAKITA SPUR GEAR 11 P/N:226924-4 Part No.: 226924-4
• 014: MAKITA SPINDLE COMPLETE P/N:140T74-0 Part No.: 140T74-0
• 015: MAKITA BALL BEARING 6002DW FOR GA5010 P/N:211247-3 Part No.: 211247-3
• 017: MAKITA GEAR HOUSING FOR DPB183/184 P/N:319980-2 Part No.: 319980-2
• 018: MAKITA BALL BEARING 6002DW FOR GA5010 P/N:211247-3 Part No.: 211247-3
• 022: MAKITA INTERNAL GEAR 40 P/N:226921-0 Part No.: 226921-0
• 023: MAKITA PAN HEAD SCREW M4X20 P/N:911138-5 Part No.: 911138-5
• 024: MAKITA HANDLE SET P/N:183R22-4 Part No.: 183R22-4
• 025: MAKITA INTERNAL GEAR 39 P/N:226922-8 Part No.: 226922-8
• 029: MAKITA SWITCH FOR DPB184/PB002G P/N:651486-7 Part No.: 651486-7
• 030: MAKITA LOCK OFF BUTTON P/N:412551-5 Part No.: 412551-5
• 031: MAKITA LED CIRCUIT FOR TD160D P/N:620521-2 Part No.: 620521-2
• 033: MAKITA CONTROLLER FOR DPB184 P/N:620D05-4 Part No.: 620D05-4
• 034: MAKITA TERMINAL FOR DTP/DDF/DHP484 P/N:643874-2 Part No.: 643874-2
• 035: MAKITA TAPPING SCREW BIND PT 3X16 FOR 6226DWE P/N:266130-9 Part No.: 266130-9
• 036: MAKITA STOP RING E-3 FOR 4304 P/N:961017-7 Part No.: 961017-7
• 037: MAKITA PIN 4 FOR 3901 P/N:256689-4 Part No.: 256689-4
• 038: MAKITA WHEEL COVER P/N:412550-7 Part No.: 412550-7
• 039: MAKITA RING SPRING 12 FOR N5900B Part No.: 231955-0
• 040: MAKITA LEVER 54 P/N:271462-1 Part No.: 271462-1
• 041: MAKITA PAN HEAD SCREW M4X20 P/N:911138-5 Part No.: 911138-5
• 042: MAKITA LEVER HOLDER P/N:459084-9 Part No.: 459084-9
• 045: MAKITA FRAME COMPLETE P/N:140V76-8 Part No.: 140V76-8
• 047: MAKITA STOPPER PLATE P/N:347696-9 Part No.: 347696-9
• 048: MAKITA FLAT WASHER 5 FOR JS1670 P/N:267010-2 Part No.: 267010-2
• 049: MAKITA NEEDLE BEARING 510 P/N:212199-1 Part No.: 212199-1
• 051: MAKITA PIN 5 FOR JS1670 P/N:256155-1 Part No.: 256155-1
• 052: MAKITA PAN HEAD SCREW M4X20 P/N:911138-5 Part No.: 911138-5
