MAKITA DHP484 CORDLESS HAMMER DRIVER DRILL SPARE PARTS

Spare Parts of Makita DHP484 Hammer Driver Drill Ref. No. Part Name & Number Price 003 MAKITA TAPPING SCREW PT M3X16 P/N:266429-2 Part No.: 266429-2 $0.22 Add To Cart 004 MAKITA F/R CHANGE LEVER FOR DC TOOL P/N:419041-9 Part No.: 419041-9 $0.44 Add To Cart 005 MAKITA SWITCH C3JW-4B FOR DDF/DHP484 P/N:650710-5 Part No.: 650710-5 $18.53 Add To Cart 006 MAKITA ROTOR FOR DDF/DHP484 P/N:619406-7 Part No.: 619406-7 $24.20 Add To Cart 007 MAKITA STATOR FOR DDF/DHP484 P/N:629225-3 Part No.: 629225-3 $11.55 Add To Cart 008 MAKITA LED CIRCUIT FOR DC-DF/HP/PB P/N:620549-0 Part No.: 620549-0 $4.03 Add To Cart 009 MAKITA TERMINAL FOR DTP/DDF/DHP484 P/N:643874-2 Part No.: 643874-2 $3.92 Add To Cart 010 MAKITA SPEED CHANGE LEVER ASSEMBLY FOR HP484D P/N:123738-1 Part No.: 123738-1 $2.40 Add To Cart 011 MAKITA TAPPING SCREW 3X20 P/N:251497-8 Part No.: 251497-8 $0.22 Add To Cart 012 MAKITA FLAT HEAD SCREW M6X22 P/N:251468-5 Part No.: 251468-5 $0.44 Add To Cart 015 MAKITA TAPPING SCREW PT 2X6 FOR DDF083 P/N:266490-9 Part No.: 266490-9 $0.33 Add To Cart 016 MAKITA CONTROLLER FOR DDF/DHP484 P/N:620548-2 Part No.: 620548-2 $89.16 Add To Cart 017 MAKITA FLAT HEAD SCREW M3X6 P/N:652069-6 Part No.: 652069-6 $0.22 Add To Cart 018 MAKITA CUSHION P/N:424517-3 Part No.: 424517-3 $0.44 Add To Cart 019 MAKITA REAR COVER FOR HP484D P/N:456967-4 Part No.: 456967-4 $1.85 Add To Cart

Brand: Makita

Specifications:

• Ref. No.: Part Name & Number
• 003: MAKITA TAPPING SCREW PT M3X16 P/N:266429-2 Part No.: 266429-2
• 004: MAKITA F/R CHANGE LEVER FOR DC TOOL P/N:419041-9 Part No.: 419041-9
• 005: MAKITA SWITCH C3JW-4B FOR DDF/DHP484 P/N:650710-5 Part No.: 650710-5
• 006: MAKITA ROTOR FOR DDF/DHP484 P/N:619406-7 Part No.: 619406-7
• 007: MAKITA STATOR FOR DDF/DHP484 P/N:629225-3 Part No.: 629225-3
• 008: MAKITA LED CIRCUIT FOR DC-DF/HP/PB P/N:620549-0 Part No.: 620549-0
• 009: MAKITA TERMINAL FOR DTP/DDF/DHP484 P/N:643874-2 Part No.: 643874-2
• 010: MAKITA SPEED CHANGE LEVER ASSEMBLY FOR HP484D P/N:123738-1 Part No.: 123738-1
• 011: MAKITA TAPPING SCREW 3X20 P/N:251497-8 Part No.: 251497-8
• 012: MAKITA FLAT HEAD SCREW M6X22 P/N:251468-5 Part No.: 251468-5
• 015: MAKITA TAPPING SCREW PT 2X6 FOR DDF083 P/N:266490-9 Part No.: 266490-9
• 016: MAKITA CONTROLLER FOR DDF/DHP484 P/N:620548-2 Part No.: 620548-2
• 017: MAKITA FLAT HEAD SCREW M3X6 P/N:652069-6 Part No.: 652069-6
• 018: MAKITA CUSHION P/N:424517-3 Part No.: 424517-3
• 019: MAKITA REAR COVER FOR HP484D P/N:456967-4 Part No.: 456967-4
