MAKITA DBS180 9MM CORDLESS BELT SANDER SPARE PARTS

Spare Parts of Makita DBS180 Belt Sander Ref. No. Part Name & Number Price 001 MAKITA LED CIRCUIT P/N:620D54-1 Part No.: 620D54-1 $5.12 Add To Cart 002 MAKITA LED HOUSING FOR DBS180 P/N:412719-3 Part No.: 412719-3 $1.42 Add To Cart 004 MAKITA M.HOUSING HANDLE COVER FOR DBS180 P/N:183R39-7 Part No.: 183R39-7 $31.61 Add To Cart 006 MAKITA TERMINAL FOR DTP/DDF/DHP484 P/N:643874-2 Part No.: 643874-2 $3.92 Add To Cart 007 MAKITA CONTROLLER FOR DBS180 P/N:620D53-3 Part No.: 620D53-3 $153.80 Add To Cart 008 MAKITA SWITCH FOR DBS180 P/N:651493-0 Part No.: 651493-0 $33.03 Add To Cart 009 MAKITA CHANGE LEVER P/N:412720-8 Part No.: 412720-8 $1.53 Add To Cart 010 MAKITA M.HOUSING HANDLE COVER FOR DBS180 P/N:183R39-7 Part No.: 183R39-7 $31.61 Add To Cart 012 MAKITA STATOR FOR DBS180 P/N:629A24-9 Part No.: 629A24-9 $63.44 Add To Cart 014 MAKITA BAFFLE PLATE P/N:412718-5 Part No.: 412718-5 $1.74 Add To Cart 016 MAKITA ROTOR ASS'Y FOR DBS180 P/N:519645-8 Part No.: 519645-8 $50.58 Add To Cart 017 MAKITA BALL BEARING 608DDW FOR HR4000C/PV7000C P/N:210005-4 Part No.: 210005-4 $1.53 Add To Cart 018 MAKITA BRACKET P/N:312A10-4 Part No.: 312A10-4 $24.42 Add To Cart 019 MAKITA TAPPING SCREW FLANGE M4X25 P/N:265999-8 Part No.: 265999-8 $0.33 Add To Cart 022 MAKITA STOP RING E-8 FOR LC1210 P/N:961014-3 Part No.: 961014-3 $0.33 Add To Cart 023 MAKITA LEVER 40 FOR SS610D P/N:272229-0 Part No.: 272229-0 $1.53 Add To Cart 025 MAKITA FLAT WASHER 5 FOR 6095DWE P/N:253807-5 Part No.: 253807-5 $0.33 Add To Cart 027 MAKITA TAPPING SCREW BIND CT 4X12 FOR 5806B P/N:266026-4 Part No.: 266026-4 $0.33 Add To Cart 029 MAKITA PULLEY COVER COMPLETE P/N:140U96-6 Part No.: 140U96-6 $36.84 Add To Cart 030 MAKITA COMPRESSION SPRING 4 FOR 8416 P/N:231026-3 Part No.: 231026-3 $0.22 Add To Cart 031 MAKITA KNOB P/N:412721-6 Part No.: 412721-6 $1.42 Add To Cart 032 MAKITA LEAF SPRING FOR 1050D P/N:232185-6 Part No.: 232185-6 $3.27 Add To Cart 033 MAKITA CAP FOR 4190DW P/N:421198-4 Part No.: 421198-4 $1.64 Add To Cart 036 MAKITA FLAT WASHER 5 FOR 6095DWE P/N:253807-5 Part No.: 253807-5 $0.33 Add To Cart 037 MAKITA THUMB SCREW M5X14 FOR HR2410 P/N:265720-5 Part No.: 265720-5 $0.76 Add To Cart 041 MAKITA FLAT WASHER 4 FOR HR3850 #47 Part No.: 941052-1 $0.22 Add To Cart 045 MAKITA HEX. SOCKET HEAD BOLT M4X10 P/N:922111-0 Part No.: 922111-0 $0.33 Add To Cart 046 MAKITA PAN HEAD SCREW M4X20 P/N:911138-5 Part No.: 911138-5 $0.33 Add To Cart 049 MAKITA ARM 9 COMPLETE FOR 9032 P/N:153310-5 Part No.: 153310-5 $35.97 Add To Cart

Brand: Makita

Specifications:

• Ref. No.: Part Name & Number
• 001: MAKITA LED CIRCUIT P/N:620D54-1 Part No.: 620D54-1
• 002: MAKITA LED HOUSING FOR DBS180 P/N:412719-3 Part No.: 412719-3
• 004: MAKITA M.HOUSING HANDLE COVER FOR DBS180 P/N:183R39-7 Part No.: 183R39-7
• 006: MAKITA TERMINAL FOR DTP/DDF/DHP484 P/N:643874-2 Part No.: 643874-2
• 007: MAKITA CONTROLLER FOR DBS180 P/N:620D53-3 Part No.: 620D53-3
• 008: MAKITA SWITCH FOR DBS180 P/N:651493-0 Part No.: 651493-0
• 009: MAKITA CHANGE LEVER P/N:412720-8 Part No.: 412720-8
• 010: MAKITA M.HOUSING HANDLE COVER FOR DBS180 P/N:183R39-7 Part No.: 183R39-7
• 012: MAKITA STATOR FOR DBS180 P/N:629A24-9 Part No.: 629A24-9
• 014: MAKITA BAFFLE PLATE P/N:412718-5 Part No.: 412718-5
• 016: MAKITA ROTOR ASS'Y FOR DBS180 P/N:519645-8 Part No.: 519645-8
• 017: MAKITA BALL BEARING 608DDW FOR HR4000C/PV7000C P/N:210005-4 Part No.: 210005-4
• 018: MAKITA BRACKET P/N:312A10-4 Part No.: 312A10-4
• 019: MAKITA TAPPING SCREW FLANGE M4X25 P/N:265999-8 Part No.: 265999-8
• 022: MAKITA STOP RING E-8 FOR LC1210 P/N:961014-3 Part No.: 961014-3
• 023: MAKITA LEVER 40 FOR SS610D P/N:272229-0 Part No.: 272229-0
• 025: MAKITA FLAT WASHER 5 FOR 6095DWE P/N:253807-5 Part No.: 253807-5
• 027: MAKITA TAPPING SCREW BIND CT 4X12 FOR 5806B P/N:266026-4 Part No.: 266026-4
• 029: MAKITA PULLEY COVER COMPLETE P/N:140U96-6 Part No.: 140U96-6
• 030: MAKITA COMPRESSION SPRING 4 FOR 8416 P/N:231026-3 Part No.: 231026-3
• 031: MAKITA KNOB P/N:412721-6 Part No.: 412721-6
• 032: MAKITA LEAF SPRING FOR 1050D P/N:232185-6 Part No.: 232185-6
• 033: MAKITA CAP FOR 4190DW P/N:421198-4 Part No.: 421198-4
• 036: MAKITA FLAT WASHER 5 FOR 6095DWE P/N:253807-5 Part No.: 253807-5
• 037: MAKITA THUMB SCREW M5X14 FOR HR2410 P/N:265720-5 Part No.: 265720-5
• 041: MAKITA FLAT WASHER 4 FOR HR3850 #47 Part No.: 941052-1
• 045: MAKITA HEX. SOCKET HEAD BOLT M4X10 P/N:922111-0 Part No.: 922111-0
• 046: MAKITA PAN HEAD SCREW M4X20 P/N:911138-5 Part No.: 911138-5
• 049: MAKITA ARM 9 COMPLETE FOR 9032 P/N:153310-5 Part No.: 153310-5
