KYORITSU CLAMP METER 2046R

Designed to meet international safety standard IEC 61010-1 CAT IV 600V. CAT IV Clamp Meters can measure the Voltage and Current in both very low and high power circuits. Thus, very useful for power distribution companies, power utilities and maintenance fields. True RMS enables an accurate measurement.

Brand: 3M

Specifications:

• AC A: 0 - 600.0A
• DC A: 0 - 600.0A
• AC V: 6/60/600V
• DC V: 600m/6/60/600V
• Ω: 600/6k/60k/600k/6M/60MΩ (Auto Ranging)
• Continuity buzzer: Buzzer Sounds at 100Ω
• Frequency/DUTY: 10/100/1k/10kHz (Auto Ranging) / 0.1 - 99.9%
• Temperature: -50ºC - +300ºC (With the use of Temperature probe 8216)
• Conductor Size: Ø33mm
• WithStand Voltage: 6880V AC For 5 Seconds
• Safety Standard: IEC 61010-1 CAT IV 600V,
• Power Source: R03 (1.5V) (AAA) &Times 2
• Dimension: 243(L) &Times 77(W) &Times 36(D)mm
• Weight: 300g
