BOSCH 12V THERMO CAMERA GTC400C

Fast exchange of data and easy documentation of thermal images with the Bosch ThermalOn app Picture-in-picture technology overlays thermal and real images for easy-to-see localisation of the measurement Flexible battery system can be powered by a 12 V LI-ION battery or with standard alkaline batteries

Brand: Bosch

Specifications:

• Battery voltage: 12.0 V
• Measurement range: -10 °C to +400 °C
• Measuring accuracy of IR: ±3.0 °C
• Measuring application: Thermal image
• Data transfer: MicroUSB, Wi-Fi
• Size of IR sensor: 160 Pixel x 120 Pixel
• Resolution: 0.1 °C
• Number of measuring points: 19,200
• Field of view (FOV): 53° x 43°
• Power supply and runtime: 4 x 1.5 V LR6 (AA), 1 x GBA 12V, 1 x GBA 10.8V
• Frame buffer (number of images): 500
• Memory type: Internal memory
• File format of image: .jpg
• Dust and splash protection: IP 53
• Weight: 0.54 kg
• Size of display: 3,5"
• Operating temperature: -10 – 45 °C
• Storage temperature: -20 – 70 °C
• Focus distance, minimum: 0.3 m
